MROD-0
|
-
Description
The MROD-0 system is made with an MCRUSH and a ShaSLINK module. This system
is studied to learn about the more complex design of the MROD-1.
The hardware of the MCRUSH and the CRUSH
module (used
for a study of the ROB design) are the same, only the FPGA is reprogrammed
with totally different logic. The MCRUSH can handle the data produced by
18 TDCs, do event building using the Tetris register (this signals availability
of the data of the event to be build), signal various error conditions
and potentially recover from errors. For testing the design the CSM has
been emulated with a ShaSLINK module
and appropriate software sending data from the PCI-bus to the S-Link output.
MCRUSH
Test
Software
