JACOUSTICS::JHead Struct Reference

Acoustic event header. More...

#include <JEvt.hh>

Inheritance diagram for JACOUSTICS::JHead:

Public Member Functions
	JHead ()
	Default constructor.
	JHead (const int detid, const JTimeRange &range, const int nhit, const int nfit, const int npar, const double ndf, const double chi2, const int ns)
	Constructor.
virtual	~JHead ()
	Virtual destructor.
	ClassDef (JHead, 7)

Public Attributes
int	detid
	detector identifier
double	UNIXTimeStart
	start time
double	UNIXTimeStop
	stop time
int	nhit
	number of hits
int	nfit
	number of hits used in fit (after outlier removal)
int	npar
	number of fit parameters
double	ndf
	weighed number of degrees of freedom
double	chi2
	chi2
int	numberOfIterations
	number of iterations

Friends
JReader &	operator>> (JReader &in, JHead &object)
	Read head from input.
JWriter &	operator<< (JWriter &out, const JHead &object)
	Write head to output.

Detailed Description

Acoustic event header.

Definition at line 157 of file JEvt.hh.

Constructor & Destructor Documentation

JHead() [1/2]

JACOUSTICS::JHead::JHead ( )

inline

Default constructor.

Definition at line 161 of file JEvt.hh.

            :
      detid(),
      UNIXTimeStart(0.0),
      UNIXTimeStop (0.0),
      nhit(0),
      nfit(0),
      npar(0),
      ndf (0.0),
      chi2(0.0),
      numberOfIterations(0)
    {}

JHead() [2/2]

JACOUSTICS::JHead::JHead ( const int detid, const JTimeRange & range, const int nhit, const int nfit, const int npar, const double ndf, const double chi2, const int ns )

inline

Constructor.

Parameters

detid	detector identifer
range	UNIX start and stop time [s]
nhit	number of hits
nfit	number of hits used in fit (after outlier removal)
npar	number of fit parameters
ndf	weighed number of degrees of freedom
chi2	chi2
ns	number of iterations

Definition at line 186 of file JEvt.hh.

                           :
      detid(detid),
      UNIXTimeStart(range.getLowerLimit()),
      UNIXTimeStop (range.getUpperLimit()),
      nhit(nhit),
      nfit(nfit),
      npar(npar),
      ndf (ndf),
      chi2(chi2),
      numberOfIterations(ns)
    {}

~JHead()

virtual JACOUSTICS::JHead::~JHead ( )

inlinevirtual

Virtual destructor.

Definition at line 209 of file JEvt.hh.

    {}

Member Function Documentation

ClassDef()

JACOUSTICS::JHead::ClassDef	(	JHead	,
		7	)

Friends And Related Symbol Documentation

operator>>

JReader & operator>> ( JReader & in, JHead & object )

friend

Read head from input.

Parameters

in	reader
object	head

Returns

reader

Definition at line 220 of file JEvt.hh.

    {
      in >> object.detid;
      in >> object.UNIXTimeStart;
      in >> object.UNIXTimeStop;
      in >> object.nhit;
      in >> object.nfit;
      in >> object.npar;
      in >> object.ndf;
      in >> object.chi2;
      in >> object.numberOfIterations;

      return in;
    }

operator<<

JWriter & operator<< ( JWriter & out, const JHead & object )

friend

Write head to output.

Parameters

out	writer
object	head

Returns

writer

Definition at line 243 of file JEvt.hh.

    {
      out << object.detid;
      out << object.UNIXTimeStart;
      out << object.UNIXTimeStop;
      out << object.nhit;
      out << object.nfit;
      out << object.npar;
      out << object.ndf;
      out << object.chi2;
      out << object.numberOfIterations;

      return out;
    }

Member Data Documentation

detid

int JACOUSTICS::JHead::detid

detector identifier

Definition at line 260 of file JEvt.hh.

UNIXTimeStart

double JACOUSTICS::JHead::UNIXTimeStart

start time

Definition at line 261 of file JEvt.hh.

UNIXTimeStop

double JACOUSTICS::JHead::UNIXTimeStop

stop time

Definition at line 262 of file JEvt.hh.

nhit

int JACOUSTICS::JHead::nhit

number of hits

Definition at line 263 of file JEvt.hh.

nfit

int JACOUSTICS::JHead::nfit

number of hits used in fit (after outlier removal)

Definition at line 264 of file JEvt.hh.

npar

int JACOUSTICS::JHead::npar

number of fit parameters

Definition at line 265 of file JEvt.hh.

ndf

double JACOUSTICS::JHead::ndf

weighed number of degrees of freedom

Definition at line 266 of file JEvt.hh.

chi2

double JACOUSTICS::JHead::chi2

chi2

Definition at line 267 of file JEvt.hh.

numberOfIterations

int JACOUSTICS::JHead::numberOfIterations

number of iterations

Definition at line 268 of file JEvt.hh.

---

The documentation for this struct was generated from the following file:

• JEvt.hh
