- Description
Since there is no standard JTAG connector defined, a NIKHEF "standard" JTAG connector was defined in order to be at least compatible within our electronics department.
In order to use the Altera ByteBlasterMV, the connections of the 10 Pin plug of the ByteBlaster cable are redefined. A schematic of the NIKHEF "Standard" ByteBlasterMV is available in PDF format.
A conversion cable is needed to connect the NIKHEF "Standard" ByteBlasterMV to CERN electronics. Note that CERN uses the original Altera standard.
