JSirene.cc File Reference

Main program to simulate detector response to muons and showers. More...

#include <string>
#include <iostream>
#include <iomanip>
#include <vector>
#include <limits>
#include <numeric>
#include "TROOT.h"
#include "TFile.h"
#include "TH1D.h"
#include "TH2D.h"
#include "TProfile.h"
#include "TProfile2D.h"
#include "TRandom3.h"
#include "km3net-dataformat/offline/Head.hh"
#include "km3net-dataformat/offline/MultiHead.hh"
#include "km3net-dataformat/offline/Evt.hh"
#include "km3net-dataformat/definitions/applications.hh"
#include "km3net-dataformat/definitions/trkmembers.hh"
#include "JLang/JSharedPointer.hh"
#include "JLang/Jpp.hh"
#include "JLang/JPredicate.hh"
#include "JSystem/JDateAndTime.hh"
#include "JPhysics/JCDFTable.hh"
#include "JPhysics/JPDFTypes.hh"
#include "JPhysics/JPDFToolkit.hh"
#include "JPhysics/JGeane.hh"
#include "JPhysics/JGeanz.hh"
#include "JPhysics/JRadiation.hh"
#include "JPhysics/JRadiationFunction.hh"
#include "JPhysics/JRadiationSource.hh"
#include "JPhysics/JACoeffSource.hh"
#include "JPhysics/JPhysicsSupportkit.hh"
#include "JTools/JFunction1D_t.hh"
#include "JTools/JFunctionalMap_t.hh"
#include "JAAnet/JAAnetToolkit.hh"
#include "JAAnet/JPDB.hh"
#include "JSirene/JSirene.hh"
#include "JSirene/pythia.hh"
#include "JSirene/JSeaWater.hh"
#include "JSirene/JCDFTable1D.hh"
#include "JSirene/JCDFTable2D.hh"
#include "JSirene/JSireneToolkit.hh"
#include "JDetector/JDetector.hh"
#include "JDetector/JDetectorSubset.hh"
#include "JDetector/JDetectorToolkit.hh"
#include "JGeometry3D/JCylinder3D.hh"
#include "JSupport/JMultipleFileScanner.hh"
#include "JSupport/JFileRecorder.hh"
#include "JSupport/JMonteCarloFileSupportkit.hh"
#include "JSupport/JSupport.hh"
#include "JSupport/JMeta.hh"
#include "Jeep/JProperties.hh"
#include "Jeep/JPrint.hh"
#include "Jeep/JTimer.hh"
#include "Jeep/JParser.hh"
#include "Jeep/JMessage.hh"

Go to the source code of this file.

Functions

int main (int argc, char **argv)


Variables

int debug
 debug level More...

int numberOfBins = 200
 number of bins for average CDF integral of optical module More...

double safetyFactor = 1.7
 safety factor for average CDF integral of optical module More...


Detailed Description

Main program to simulate detector response to muons and showers.

Picture by Claudine Colnard

Note that CDF file descriptor should contain the wild card character JPHYSICS::WILDCARD;
The file names are obtained by replacing JPHYSICS::WILDCARD; with

More accuracy can be achieved by setting compile option RADITION but it will run slower.

The CDF tables can be produced with the script JMakePDF.sh:

JMakePDF.sh -P

(option -h will print all available options). Note that the script will launch a large number of processes (JMakePDF and JMakePDG)
which may take a considerable amount of time to completion.
On a standard desktop, all jobs should be finished within 1/2 a day or so.

The same script should then be run with option -M to merge the PDF files, i.e:

JMakePDF.sh -M

CDF tables are obtained by running the same script with option -C, i.e:

JMakePDF.sh -C

The various PDFs can be drawn using the JDrawPDF or JDrawPDG applications.
The tabulated PDFs can be plotted using the JPlotPDF or JPlotPDG applications.
The tabulated CDFs can be plotted using the JPlotCDF or JPlotCDG applications.

Author
mdejong

Definition in file JSirene.cc.

Function Documentation

int main ( int  argc,
char **  argv
)

Definition at line 197 of file JSirene.cc.

198 {
199  using namespace std;
200  using namespace JPP;
201
202  string fileDescriptor;
203  JMultipleFileScanner<JAAnetTypes_t> inputFile;
204  JFileRecorder <JTYPELIST<JAAnetTypes_t, JMetaTypes_t, JRootTypes_t>::typelist> outputFile;
205  JLimit_t& numberOfEvents = inputFile.getLimit();
206  string detectorFile;
207  JParameters parameters;
208  bool writeEMShowers;
209  size_t numberOfHits;
210  double factor;
211  UInt_t seed;
212
213  try {
214
215  JProperties properties;
216
217  properties.insert(gmake_property(parameters.Ecut_GeV));
218  properties.insert(gmake_property(parameters.Emin_GeV));
219  properties.insert(gmake_property(parameters.Dmin_m));
220  properties.insert(gmake_property(parameters.Emax_GeV));
221  properties.insert(gmake_property(parameters.Dmax_m));
222  properties.insert(gmake_property(parameters.Tmax_ns));
223  properties.insert(gmake_property(parameters.Nmax_NPE));
224  properties.insert(gmake_property(parameters.Nmax_PMT));
225
226  properties.insert(gmake_property(numberOfBins));
227  properties.insert(gmake_property(safetyFactor));
228
229  JParser<> zap("Main program to simulate detector response to muons and showers.");
230
231  zap['@'] = make_field(properties) = JPARSER::initialised();
232  zap['F'] = make_field(fileDescriptor, "file name descriptor for CDF tables");
233  zap['f'] = make_field(inputFile) = JPARSER::initialised();
234  zap['o'] = make_field(outputFile) = "sirene.root";
235  zap['n'] = make_field(numberOfEvents) = JLimit::max();
236  zap['a'] = make_field(detectorFile) = "";
237  zap['s'] = make_field(writeEMShowers, "store generated EM showers in event");
238  zap['N'] = make_field(numberOfHits, "minimum number of hits to output event") = 1;
239  zap['U'] = make_field(factor, "scaling factor applied to light yields") = 1.0;
240  zap['S'] = make_field(seed) = 0;
241  zap['d'] = make_field(debug) = 1;
242
243  zap(argc, argv);
244  }
245  catch(const exception &error) {
246  FATAL(error.what() << endl);
247  }
248
249
250  gRandom->SetSeed(seed);
251
252
253  const JMeta meta(argc, argv);
254
255  const double Zbed = 0.0; // level of seabed [m]
256
257  vector<JCDF_t> CDF;
258  vector<JCDG_t> CDG;
259
260  CDF.push_back(JCDF_t(fileDescriptor, DIRECT_LIGHT_FROM_MUON));
261  CDF.push_back(JCDF_t(fileDescriptor, SCATTERED_LIGHT_FROM_MUON));
262  CDF.push_back(JCDF_t(fileDescriptor, DIRECT_LIGHT_FROM_DELTARAYS));
263  CDF.push_back(JCDF_t(fileDescriptor, SCATTERED_LIGHT_FROM_DELTARAYS));
264
265  CDG.push_back(JCDG_t(fileDescriptor, DIRECT_LIGHT_FROM_EMSHOWER));
266  CDG.push_back(JCDG_t(fileDescriptor, SCATTERED_LIGHT_FROM_EMSHOWER));
267
268
269  double maximal_road_width = 0.0; // road width [m]
270  double maximal_distance = 0.0; // road width [m]
271
272  for (size_t i = 0; i != CDF.size(); ++i) {
273
274  DEBUG("Range CDF["<< CDF[i].type << "] " << CDF[i].function.intensity.getXmax() << " m" << endl);
275
276  maximal_road_width = max(maximal_road_width, CDF[i].function.intensity.getXmax());
277  }
278
279  for (size_t i = 0; i != CDG.size(); ++i) {
280
281  DEBUG("Range CDG["<< CDG[i].type << "] " << CDG[i].function.intensity.getXmax() << " m" << endl);
282
283  if (!is_scattered(CDF[i].type)) {
284  maximal_road_width = max(maximal_road_width, CDG[i].function.intensity.getXmax());
285  }
286
287  maximal_distance = max(maximal_distance, CDG[i].function.intensity.getXmax());
288  }
289
290  NOTICE("Maximal road width [m] " << maximal_road_width << endl);
291  NOTICE("Maximal distance [m] " << maximal_distance << endl);
292
293
294  if (detectorFile == "" || inputFile.empty()) {
295  STATUS("Nothing to be done." << endl);
296  return 0;
297  }
298
299  JDetector detector;
300
301  try {
302
303  STATUS("Load detector... " << flush);
304
305  load(detectorFile, detector);
306
307  STATUS("OK" << endl);
308  }
309  catch(const JException& error) {
310  FATAL(error);
311  }
312
313  // remove empty modules
314
315  for (JDetector::iterator module = detector.begin(); module != detector.end(); ) {
316  if (!module->empty())
317  ++module;
318  else
319  module = detector.erase(module);
320  }
321
322  vector< JSharedPointer<JRadiationInterface> > radiation;
323  vector< JSharedPointer<JACoeffInterface> > ionization;
324
325  if (true) {
326
327  STATUS("Setting up radiation tables... " << flush);
328
329  const JRadiation hydrogen ( 1.0, 1.0, 40, 0.01, 0.1, 0.1);
330  const JRadiation oxygen ( 8.0, 16.0, 40, 0.01, 0.1, 0.1);
331  const JRadiation chlorine (17.0, 35.5, 40, 0.01, 0.1, 0.1);
332  const JRadiation sodium (11.0, 23.0, 40, 0.01, 0.1, 0.1);
333 #ifdef RADIATION
334  const JRadiation calcium (20.0, 40.0, 40, 0.01, 0.1, 0.1);
335  const JRadiation magnesium(12.0, 24.3, 40, 0.01, 0.1, 0.1);
336  const JRadiation potassium(19.0, 39.0, 40, 0.01, 0.1, 0.1);
337  const JRadiation sulphur (16.0, 32.0, 40, 0.01, 0.1, 0.1);
338 #endif
339
340  JSharedPointer<JRadiation> Hydrogen (new JRadiationFunction(hydrogen, 300, 0.2, 1.0e11));
341  JSharedPointer<JRadiation> Oxygen (new JRadiationFunction(oxygen, 300, 0.2, 1.0e11));
342  JSharedPointer<JRadiation> Chlorine (new JRadiationFunction(chlorine, 300, 0.2, 1.0e11));
343  JSharedPointer<JRadiation> Sodium (new JRadiationFunction(sodium, 300, 0.2, 1.0e11));
344 #ifdef RADIATION
345  JSharedPointer<JRadiation> Calcium (new JRadiationFunction(calcium, 300, 0.2, 1.0e11));
346  JSharedPointer<JRadiation> Magnesium(new JRadiationFunction(magnesium,300, 0.2, 1.0e11));
347  JSharedPointer<JRadiation> Potassium(new JRadiationFunction(potassium,300, 0.2, 1.0e11));
348  JSharedPointer<JRadiation> Sulphur (new JRadiationFunction(sulphur, 300, 0.2, 1.0e11));
349 #endif
350
351  radiation.push_back(new JRadiationSource(11, Oxygen, DENSITY_SEA_WATER * JSeaWater::O(), EErad_t));
352  radiation.push_back(new JRadiationSource(12, Chlorine, DENSITY_SEA_WATER * JSeaWater::Cl(), EErad_t));
353  radiation.push_back(new JRadiationSource(13, Hydrogen, DENSITY_SEA_WATER * JSeaWater::H(), EErad_t));
354  radiation.push_back(new JRadiationSource(14, Sodium, DENSITY_SEA_WATER * JSeaWater::Na(), EErad_t));
355 #ifdef RADIATION
356  radiation.push_back(new JRadiationSource(15, Calcium, DENSITY_SEA_WATER * JSeaWater::Ca(), EErad_t));
357  radiation.push_back(new JRadiationSource(16, Magnesium,DENSITY_SEA_WATER * JSeaWater::Mg(), EErad_t));
358  radiation.push_back(new JRadiationSource(17, Potassium,DENSITY_SEA_WATER * JSeaWater::K(), EErad_t));
359  radiation.push_back(new JRadiationSource(18, Sulphur, DENSITY_SEA_WATER * JSeaWater::S(), EErad_t));
360 #endif
361
362  radiation.push_back(new JRadiationSource(21, Oxygen, DENSITY_SEA_WATER * JSeaWater::O(), Brems_t));
363  radiation.push_back(new JRadiationSource(22, Chlorine, DENSITY_SEA_WATER * JSeaWater::Cl(), Brems_t));
364  radiation.push_back(new JRadiationSource(23, Hydrogen, DENSITY_SEA_WATER * JSeaWater::H(), Brems_t));
365  radiation.push_back(new JRadiationSource(24, Sodium, DENSITY_SEA_WATER * JSeaWater::Na(), Brems_t));
366 #ifdef RADIATION
367  radiation.push_back(new JRadiationSource(25, Calcium, DENSITY_SEA_WATER * JSeaWater::Ca(), Brems_t));
368  radiation.push_back(new JRadiationSource(26, Magnesium,DENSITY_SEA_WATER * JSeaWater::Mg(), Brems_t));
369  radiation.push_back(new JRadiationSource(27, Potassium,DENSITY_SEA_WATER * JSeaWater::K(), Brems_t));
370  radiation.push_back(new JRadiationSource(28, Sulphur, DENSITY_SEA_WATER * JSeaWater::S(), Brems_t));
371 #endif
372
373  radiation.push_back(new JRadiationSource(31, Oxygen, DENSITY_SEA_WATER * JSeaWater::O(), GNrad_t));
374  radiation.push_back(new JRadiationSource(32, Chlorine, DENSITY_SEA_WATER * JSeaWater::Cl(), GNrad_t));
375  radiation.push_back(new JRadiationSource(33, Hydrogen, DENSITY_SEA_WATER * JSeaWater::H(), GNrad_t));
376  radiation.push_back(new JRadiationSource(34, Sodium, DENSITY_SEA_WATER * JSeaWater::Na(), GNrad_t));
377 #ifdef RADIATION
378  radiation.push_back(new JRadiationSource(35, Calcium, DENSITY_SEA_WATER * JSeaWater::Ca(), GNrad_t));
379  radiation.push_back(new JRadiationSource(36, Magnesium,DENSITY_SEA_WATER * JSeaWater::Mg(), GNrad_t));
380  radiation.push_back(new JRadiationSource(37, Potassium,DENSITY_SEA_WATER * JSeaWater::K(), GNrad_t));
381  radiation.push_back(new JRadiationSource(38, Sulphur, DENSITY_SEA_WATER * JSeaWater::S(), GNrad_t));
382 #endif
383
384  radiation.push_back(new JDISSource(100, DENSITY_SEA_WATER));
385
386  ionization.push_back(new JACoeffSource(Oxygen, DENSITY_SEA_WATER * JSeaWater::O()));
387  ionization.push_back(new JACoeffSource(Chlorine, DENSITY_SEA_WATER * JSeaWater::Cl()));
388  ionization.push_back(new JACoeffSource(Hydrogen, DENSITY_SEA_WATER * JSeaWater::H()));
389  ionization.push_back(new JACoeffSource(Sodium, DENSITY_SEA_WATER * JSeaWater::Na()));
390 #ifdef RADIATION
391  ionization.push_back(new JACoeffSource(Calcium, DENSITY_SEA_WATER * JSeaWater::Ca()));
392  ionization.push_back(new JACoeffSource(Magnesium,DENSITY_SEA_WATER * JSeaWater::Mg()));
393  ionization.push_back(new JACoeffSource(Potassium,DENSITY_SEA_WATER * JSeaWater::K()));
394  ionization.push_back(new JACoeffSource(Sulphur, DENSITY_SEA_WATER * JSeaWater::S()));
395 #endif
396
397  STATUS("OK" << endl);
398  }
399
400
401  JCylinder3D cylinder(detector.begin(), detector.end());
402
403  cylinder.addMargin(maximal_distance);
404
405  if (cylinder.getZmin() < Zbed) {
406  cylinder.setZmin(Zbed);
407  }
408
409  NOTICE("Light generation volume: " << cylinder << endl);
410
411
412  Vec offset(0,0,0);
413  Head header;
414
415  try {
416
417  header = inputFile.getHeader();
418
419  JHead buffer(header);
420
421  buffer.simul.push_back(JAANET::simul());
422
423  buffer.simul.rbegin()->program = APPLICATION_JSIRENE;
424  buffer.simul.rbegin()->version = getGITVersion();
425  buffer.simul.rbegin()->date = getDate();
426  buffer.simul.rbegin()->time = getTime();
427
428  buffer.push(&JHead::simul);
429
430  buffer.detector.push_back(JAANET::detector());
431
432  buffer.detector.rbegin()->program = APPLICATION_JSIRENE;
433  buffer.detector.rbegin()->filename = detectorFile;
434
435  buffer.push(&JHead::detector);
436
437  offset += Vec(cylinder.getX(), cylinder.getY(), 0.0);
438  offset -= getOrigin(buffer);
439
440  if (buffer.is_valid(&JHead::fixedcan)) {
441  buffer.fixedcan.xcenter += offset.x;
442  buffer.fixedcan.ycenter += offset.y;
443  buffer.fixedcan.zmin += offset.z;
444  buffer.fixedcan.zmax += offset.z;
445  } else {
446  buffer.fixedcan.xcenter = cylinder.getX();
447  buffer.fixedcan.ycenter = cylinder.getY();
448  buffer.fixedcan.radius = cylinder.getRadius();
449  buffer.fixedcan.zmin = cylinder.getZmin();
450  buffer.fixedcan.zmax = cylinder.getZmax();
451  }
452
453  buffer.push(&JHead::fixedcan);
454
455  if (buffer.is_valid(&JHead::coord_origin)) {
456
457  buffer.coord_origin = coord_origin(0.0, 0.0, 0.0);
458
459  buffer.push(&JHead::coord_origin);
460  }
461
462  copy(buffer, header);
463  }
464  catch(const JException& error) {
465  FATAL(error);
466  }
467
468  NOTICE("Offset applied to true tracks is: " << offset << endl);
469
470  TH1D job("job", NULL, 400, 0.5, 400.5);
471  TProfile cpu("cpu", NULL, 16, 0.0, 8.0);
472  TProfile2D rms("rms", NULL, 16, 0.0, 8.0, 201, -0.5, 200.5);
473  TProfile2D rad("rad", NULL, 16, 0.0, 8.0, 201, -0.5, 200.5);
474
475
476  outputFile.open();
477
478  if (!outputFile.is_open()) {
479  FATAL("Error opening file " << outputFile << endl);
480  }
481
482  outputFile.put(meta);
483  outputFile.put(header);
484  outputFile.put(*gRandom);
485
486  const double epsilon = 1.0e-6; // precision angle [rad]
487  const JRange<double> pi(epsilon, PI - epsilon); // constrain angle
488
489  JTimer timer;
490
491  for (JMultipleFileScanner<Evt>& in = inputFile; in.hasNext(); ) {
492
493  STATUS("event: " << setw(10) << in.getCounter() << '\r'); DEBUG(endl);
494
495  job.Fill(1.0);
496
497  Evt* evt = in.next();
498
499  for (vector<Trk>::iterator track = evt->mc_trks.begin(); track != evt->mc_trks.end(); ++track) {
500  track->pos += offset;
501  }
502
503  Evt event(*evt); // output
504
505  event.mc_hits.clear();
506
507  JHits_t mc_hits; // temporary buffer
508
509  timer.reset();
510  timer.start();
511
512  for (vector<Trk>::const_iterator track = evt->mc_trks.begin(); track != evt->mc_trks.end(); ++track) {
513
514  if (!track->is_finalstate()) {
515  continue; // only final state particles produce light
516  }
517
518  if (is_muon(*track)) {
519
520  // -----------------------------------------------
521  // muon
522  // -----------------------------------------------
523
524  job.Fill(2.0);
525
526  typedef JDetectorSubset<JModuleComparator3Z_t> JDetectorSubset_t;
527
528  const JCylinder3D::intersection_type intersection = cylinder.getIntersection(getAxis(*track));
529
530  double Zmin = intersection.first;
531  double Zmax = intersection.second;
532
533  if (Zmax - Zmin <= parameters.Dmin_m) {
534  continue;
535  }
536
537  JVertex vertex(0.0, track->t, track->E); // start of muon
538
539  if (track->pos.z < Zbed) { // propagate muon through rock
540
541  if (track->dir.z > 0.0)
542  vertex.step(gRock, (Zbed - track->pos.z) / track->dir.z);
543  else
544  continue;
545  }
546
547  if (vertex.getZ() < Zmin) { // propagate muon through water
548  vertex.step(gWater, Zmin - vertex.getZ());
549  }
550
551  if (vertex.getRange() <= parameters.Dmin_m) {
552  continue;
553  }
554
555  job.Fill(3.0);
556
557  const JDetectorSubset_t subdetector(detector, getAxis(*track), maximal_road_width);
558
559  if (subdetector.empty()) {
560  continue;
561  }
562
563  job.Fill(4.0);
564
565  JTrack muon(vertex); // propagate muon trough detector
566
567  while (vertex.getE() >= parameters.Emin_GeV && vertex.getZ() < Zmax) {
568
569  const int N = radiation.size();
570
571  double li[N]; // inverse interaction lengths
572  double ls = 1.0e-5; // minimal total inverse interaction length [m^-1]
573
574  for (int i = 0; i != N; ++i) {
575  ls += li[i] = radiation[i]->getInverseInteractionLength(vertex.getE());
576  }
577
578  double As = 0.0; // ionization energy loss
579
580  for (size_t i = 0; i != ionization.size(); ++i) {
581  As += ionization[i]->getA(vertex.getE());
582  }
583
584  double step = gRandom->Exp(1.0) / ls; // distance to next radiation process
585  double range = vertex.getRange(As); // range of muon
586
587  if (vertex.getE() < parameters.Emax_GeV) { // limited step size
588  if (parameters.Dmax_m < range) {
589  range = parameters.Dmax_m;
590  }
591  }
592
593  double ts = getThetaMCS(vertex.getE(), min(step,range)); // multiple Coulomb scattering angle [rad]
594  double T2 = ts*ts; //
595
596  rms.Fill(log10(vertex.getE()), (Double_t) 0, ts*ts);
597
598  vertex.getDirection() += getRandomDirection(T2/3.0); // multiple Coulomb planar scattering
599
600  vertex.step(As, min(step,range)); // ionization energy loss
601
602  double Es = 0.0; // shower energy [GeV]
603
604  if (step < range) {
605
606  if (vertex.getE() >= parameters.Emin_GeV) {
607
608  double y = gRandom->Uniform(ls);
609
610  for (int i = 0; i != N; ++i) {
611
612  y -= li[i];
613
614  if (y < 0.0) {
615
616  Es = radiation[i]->getEnergyOfShower(vertex.getE()); // shower energy [GeV]
617  ts = radiation[i]->getThetaRMS(vertex.getE(), Es); // scattering angle [rad]
618
619  T2 += ts*ts;
620
621  rms.Fill(log10(vertex.getE()), (Double_t) radiation[i]->getID(), ts*ts);
622  rad.Fill(log10(vertex.getE()), (Double_t) radiation[i]->getID(), Es);
623
624  break;
625  }
626  }
627  }
628  }
629
630  vertex.applyEloss(getRandomDirection(T2), Es);
631
632  muon.push_back(vertex);
633  }
634
635  // add muon end point
636
637  if (vertex.getZ() < Zmax && vertex.getRange() > 0.0) {
638
639  vertex.step(vertex.getRange());
640
641  muon.push_back(vertex);
642  }
643
644  // add information to output muon
645
646  vector<Trk>::iterator trk = find_if(event.mc_trks.begin(),
647  event.mc_trks.end(),
648  make_predicate(&Trk::id, track->id));
649
650  if (trk != event.mc_trks.end()) {
651  trk->len = (muon.rbegin()->getZ() < Zmax ? +1 : -1) * (muon.rbegin()->getZ() - muon.begin()->getZ());
652  trk->setusr(mc_usr_keys::energy_lost_in_can, muon.begin()->getE() - muon.rbegin()->getE());
653  }
654
655  for (JDetector::const_iterator module = subdetector.begin(); module != subdetector.end(); ++module) {
656
657  const double z0 = muon.begin()->getZ();
658  const double t0 = muon.begin()->getT();
659  const double Z = module->getZ() - module->getX() / getTanThetaC();
660
661  if (Z >= muon.begin()->getZ() && Z <= muon.rbegin()->getZ()) {
662
663  const JVector2D pos = muon.getPosition(Z);
664  const double R = hypot(module->getX() - pos.getX(),
665  module->getY() - pos.getY());
666
667  for (size_t i = 0; i != CDF.size(); ++i) {
668
669  if (R < CDF[i].integral.getXmax()) {
670
671  try {
672
673  double W = 1.0; // mip
674
675  if (is_deltarays(CDF[i].type)) {
676  W = getDeltaRaysFromMuon(muon.getE(Z)); // delta-rays
677  }
678
679  const double NPE = CDF[i].integral.getNPE(R) * module->size() * factor * W;
680  const int N = gRandom->Poisson(NPE);
681
682  if (N != 0) {
683
684  vector<double> npe;
685
686  for (JModule::const_iterator pmt = module->begin(); pmt != module->end(); ++pmt) {
687
688  const double R = hypot(pmt->getX() - pos.getX(),
689  pmt->getY() - pos.getY());
690  const double theta = pi.constrain(pmt->getTheta());
691  const double phi = pi.constrain(fabs(pmt->getPhi()));
692
693  npe.push_back(CDF[i].function.getNPE(R, theta, phi) * factor * W);
694  }
695
696  const vector<size_t>& ns = getNumberOfPhotoElectrons(NPE, N, npe, NPE < parameters.Nmax_NPE);
697
698  for (JModule::const_iterator pmt = module->begin(); pmt != module->end(); ++pmt) {
699
700  const double R = hypot(pmt->getX() - pos.getX(),
701  pmt->getY() - pos.getY());
702  const double Z = pmt->getZ() - z0;
703  const double theta = pi.constrain(pmt->getTheta());
704  const double phi = pi.constrain(fabs(pmt->getPhi()));
705
706  size_t n0 = min(ns[distance(module->begin(),pmt)], parameters.Nmax_PMT);
707
708  job.Fill((double) (100 + CDF[i].type), (double) n0);
709
710  while (n0 != 0) {
711
712  const double t1 = CDF[i].function.getTime(R, theta, phi, gRandom->Rndm());
713  const int n1 = getNumberOfPhotoElectrons(n0);
714
715  mc_hits.push_back(JHit_t(mc_hits.size() + 1,
716  pmt->getID(),
717  getHitType(CDF[i].type),
718  track->id,
719  t0 + (R * getTanThetaC() + Z) / C + t1,
720  n1));
721
722  n0 -= n1;
723  }
724  }
725
726  if (std::accumulate(npe.begin(), npe.end(), 0.0) > NPE) {
727  job.Fill((double) (300 + CDF[i].type));
728  }
729  }
730  }
731  catch(const exception& error) {
732  job.Fill((double) (200 + CDF[i].type));
733  }
734  }
735  }
736  }
737  }
738
739  for (JTrack::const_iterator vertex = muon.begin(); vertex != muon.end(); ++vertex) {
740
741  const double Es = vertex->getEs();
742
743  if (Es >= parameters.Ecut_GeV) {
744
745  const double z0 = vertex->getZ();
746  const double t0 = vertex->getT();
747  const double DZ = geanz.getMaximum(Es);
748
749  int origin = track->id;
750
751  if (writeEMShowers) {
752  origin = event.mc_trks.size() + 1;
753  }
754
755  int number_of_hits = 0;
756
757  JDetectorSubset_t::range_type range = subdetector.getRange(z0 - maximal_distance,
758  z0 + maximal_distance);
759
760  for (JDetector::const_iterator module = range.begin(); module != range.end(); ++module) {
761
762  const double R = hypot(module->getX() - vertex->getX(),
763  module->getY() - vertex->getY());
764  const double Z = module->getZ() - z0 - DZ;
765  const double D = sqrt(R*R + Z*Z);
766  const double cd = Z / D;
767
768  for (size_t i = 0; i != CDG.size(); ++i) {
769
770  if (D < CDG[i].integral.getXmax()) {
771
772  try {
773
774  const double NPE = CDG[i].integral.getNPE(D, cd) * Es * module->size() * factor;
775  const int N = gRandom->Poisson(NPE);
776
777  if (N != 0) {
778
779  vector<double> npe;
780
781  for (JModule::const_iterator pmt = module->begin(); pmt != module->end(); ++pmt) {
782
783  const double R = hypot(pmt->getX() - vertex->getX(),
784  pmt->getY() - vertex->getY());
785  const double Z = pmt->getZ() - z0 - DZ;
786  const double D = sqrt(R*R + Z*Z);
787  const double cd = Z / D;
788  const double theta = pi.constrain(pmt->getTheta());
789  const double phi = pi.constrain(fabs(pmt->getPhi()));
790
791  npe.push_back(CDG[i].function.getNPE(D, cd, theta, phi) * Es * factor);
792  }
793
794  const vector<size_t>& ns = getNumberOfPhotoElectrons(NPE, N, npe, NPE < parameters.Nmax_NPE);
795
796  for (JModule::const_iterator pmt = module->begin(); pmt != module->end(); ++pmt) {
797
798  const double R = hypot(pmt->getX() - vertex->getX(),
799  pmt->getY() - vertex->getY());
800  const double theta = pi.constrain(pmt->getTheta());
801  const double phi = pi.constrain(fabs(pmt->getPhi()));
802
803  size_t n0 = min(ns[distance(module->begin(),pmt)], parameters.Nmax_PMT);
804
805  job.Fill((double) (100 + CDG[i].type), (double) n0);
806
807  while (n0 != 0) {
808
809  const double dz = geanz.getLength(Es, gRandom->Rndm());
810  const double Z = pmt->getZ() - z0 - dz;
811  const double D = sqrt(R*R + Z*Z);
812  const double cd = Z / D;
813
814  const double t1 = CDG[i].function.getTime(D, cd, theta, phi, gRandom->Rndm());
815  const int n1 = getNumberOfPhotoElectrons(n0);
816
817  mc_hits.push_back(JHit_t(mc_hits.size() + 1,
818  pmt->getID(),
819  getHitType(CDG[i].type),
820  origin,
821  t0 + (dz + D * getIndexOfRefraction()) / C + t1,
822  n1));
823
824  n0 -= n1;
825
826  number_of_hits += n1;
827  }
828  }
829
830  if (std::accumulate(npe.begin(), npe.end(), 0.0) > NPE) {
831  job.Fill((double) (300 + CDG[i].type));
832  }
833  }
834  }
835  catch(const exception& error) {
836  job.Fill((double) (200 + CDG[i].type));
837  }
838  }
839  }
840  }
841
842  if (writeEMShowers && number_of_hits != 0) {
843
844  event.mc_trks.push_back(JTrk_t(origin,
845  TRACK_TYPE_PHOTON,
846  track->id,
847  track->pos + track->dir * vertex->getZ(),
848  track->dir,
849  vertex->getT(),
850  Es));
851  }
852  }
853  }
854
855  } else if (track->len > 0.0) {
856
857  // -----------------------------------------------
858  // decayed particles treated as mip (tau includes mip+deltaray)
859  // -----------------------------------------------
860
861  job.Fill(6.0);
862
863  const double z0 = 0.0;
864  const double z1 = z0 + track->len;
865  const double t0 = track->t;
866  const double E = track->E;
867
868  const JTransformation3D transformation = getTransformation(*track);
869
870  JModule buffer;
871
872  for (JDetector::const_iterator module = detector.begin(); module != detector.end(); ++module) {
873
874  const JPosition3D pos = transformation.transform(module->getPosition());
875
876  const double R = pos.getX();
877  const double Z = pos.getZ() - R / getTanThetaC();
878
879  if (Z < z0 ||
880  Z > z1 ||
881  R > maximal_road_width) {
882  continue;
883  }
884
885  for (size_t i = 0; i != CDF.size(); ++i) {
886
887  double W = 1.0; // mip
888
889  if (is_deltarays(CDF[i].type)) {
890
891  if (is_tau(*track))
892  W = getDeltaRaysFromTau(E); // delta-rays
893  else
894  continue;
895  }
896
897  if (R < CDF[i].integral.getXmax()) {
898
899  try {
900
901  const double NPE = CDF[i].integral.getNPE(R) * module->size() * factor * W;
902  const int N = gRandom->Poisson(NPE);
903
904  if (N != 0) {
905
906  buffer = *module;
907
908  buffer.transform(transformation);
909
910  vector<double> npe;
911
912  for (JModule::const_iterator pmt = buffer.begin(); pmt != buffer.end(); ++pmt) {
913
914  const double R = pmt->getX();
915  const double theta = pi.constrain(pmt->getTheta());
916  const double phi = pi.constrain(fabs(pmt->getPhi()));
917
918  npe.push_back(CDF[i].function.getNPE(R, theta, phi) * factor * W);
919  }
920
921  const vector<size_t>& ns = getNumberOfPhotoElectrons(NPE, N, npe, NPE < parameters.Nmax_NPE);
922
923  for (JModule::const_iterator pmt = buffer.begin(); pmt != buffer.end(); ++pmt) {
924
925  const double R = pmt->getX();
926  const double Z = pmt->getZ() - z0;
927  const double theta = pi.constrain(pmt->getTheta());
928  const double phi = pi.constrain(fabs(pmt->getPhi()));
929
930  size_t n0 = min(ns[distance(buffer.cbegin(),pmt)], parameters.Nmax_PMT);
931
932  job.Fill((double) (120 + CDF[i].type), (double) n0);
933
934  while (n0 != 0) {
935
936  const double t1 = CDF[i].function.getTime(R, theta, phi, gRandom->Rndm());
937  const int n1 = getNumberOfPhotoElectrons(n0);
938
939  mc_hits.push_back(JHit_t(mc_hits.size() + 1,
940  pmt->getID(),
941  getHitType(CDF[i].type),
942  track->id,
943  t0 + (R * getTanThetaC() + Z) / C + t1,
944  n1));
945
946  n0 -= n1;
947  }
948  }
949
950  if (std::accumulate(npe.begin(), npe.end(), 0.0) > NPE) {
951  job.Fill((double) (320 + CDF[i].type));
952  }
953  }
954  }
955  catch(const exception& error) {
956  job.Fill((double) (220 + CDF[i].type));
957  }
958
959  }
960  }
961  }
962
963  if (!buffer.empty()) {
964  job.Fill(7.0);
965  }
966
967  } else if (!is_neutrino(*track)) {
968
969  if (JPDB::getInstance().hasPDG(track->type)) {
970
971  // -----------------------------------------------
972  // electron or hadron
973  // -----------------------------------------------
974
975  job.Fill(8.0);
976
977  double E = track->E;
978
979  try {
980  E = getKineticEnergy(E, JPDB::getInstance().getPDG(track->type).mass);
981  }
982  catch(const exception& error) {
983  ERROR(error.what() << endl);
984  }
985
986  E = pythia(track->type, E);
987
988  if (E >= parameters.Ecut_GeV && cylinder.getDistance(getPosition(*track)) < parameters.Dmin_m) {
989
990  const double z0 = 0.0;
991  const double t0 = track->t;
992  const double DZ = geanz.getMaximum(E);
993
994  const JTransformation3D transformation = getTransformation(*track);
995
996  JModule buffer;
997
998  for (JDetector::const_iterator module = detector.begin(); module != detector.end(); ++module) {
999
1000  const JPosition3D pos = transformation.transform(module->getPosition());
1001
1002  const double R = pos.getX();
1003  const double Z = pos.getZ() - z0 - DZ;
1004  const double D = sqrt(R*R + Z*Z);
1005  const double cd = Z / D;
1006
1007  for (size_t i = 0; i != CDG.size(); ++i) {
1008
1009  if (D < CDG[i].integral.getXmax()) {
1010
1011  try {
1012
1013  const double NPE = CDG[i].integral.getNPE(D, cd) * E * module->size() * factor;
1014  const int N = gRandom->Poisson(NPE);
1015
1016  if (N != 0) {
1017
1018  buffer = *module;
1019
1020  buffer.transform(transformation);
1021
1022  vector<double> npe;
1023
1024  for (JModule::const_iterator pmt = buffer.begin(); pmt != buffer.end(); ++pmt) {
1025
1026  const double R = pmt->getX();
1027  const double Z = pmt->getZ() - z0 - DZ;
1028  const double D = sqrt(R*R + Z*Z);
1029  const double cd = Z / D;
1030  const double theta = pi.constrain(pmt->getTheta());
1031  const double phi = pi.constrain(fabs(pmt->getPhi()));
1032
1033  npe.push_back(CDG[i].function.getNPE(D, cd, theta, phi) * E * factor);
1034  }
1035
1036  const vector<size_t>& ns = getNumberOfPhotoElectrons(NPE, N, npe, NPE < parameters.Nmax_NPE);
1037
1038  for (JModule::const_iterator pmt = buffer.begin(); pmt != buffer.end(); ++pmt) {
1039
1040  const double theta = pi.constrain(pmt->getTheta());
1041  const double phi = pi.constrain(fabs(pmt->getPhi()));
1042
1043  size_t n0 = min(ns[distance(buffer.cbegin(),pmt)], parameters.Nmax_PMT);
1044
1045  job.Fill((double) (140 + CDG[i].type), (double) n0);
1046
1047  while (n0 != 0) {
1048
1049  const double dz = geanz.getLength(E, gRandom->Rndm());
1050  const double Z = pmt->getZ() - z0 - dz;
1051  const double D = sqrt(R*R + Z*Z);
1052  const double cd = Z / D;
1053
1054  const double t1 = CDG[i].function.getTime(D, cd, theta, phi, gRandom->Rndm());
1055  const int n1 = getNumberOfPhotoElectrons(n0);
1056
1057  mc_hits.push_back(JHit_t(mc_hits.size() + 1,
1058  pmt->getID(),
1059  getHitType(CDG[i].type, true),
1060  track->id,
1061  t0 + (dz + D * getIndexOfRefraction()) / C + t1,
1062  n1));
1063
1064  n0 -= n1;
1065  }
1066  }
1067
1068  if (std::accumulate(npe.begin(), npe.end(), 0.0) > NPE) {
1069  job.Fill((double) (340 + CDG[i].type));
1070  }
1071  }
1072  }
1073  catch(const exception& error) {
1074  job.Fill((double) (240 + CDG[i].type));
1075  }
1076  }
1077  }
1078  }
1079
1080  if (!buffer.empty()) {
1081  job.Fill(9.0);
1082  }
1083
1084  } else {
1085  job.Fill(21.0);
1086  }
1087  }
1088  }
1089  }
1090
1091  if (!mc_hits.empty()) {
1092
1093  mc_hits.merge(parameters.Tmax_ns);
1094
1095  event.mc_hits.resize(mc_hits.size());
1096
1097  copy(mc_hits.begin(), mc_hits.end(), event.mc_hits.begin());
1098  }
1099
1100  timer.stop();
1101
1102  if (has_neutrino(event)) {
1103  cpu.Fill(log10(get_neutrino(event).E), (double) timer.usec_ucpu * 1.0e-3);
1104  }
1105
1106  if (event.mc_hits.size() >= numberOfHits) {
1107
1108  outputFile.put(event);
1109
1110  job.Fill(10.0);
1111  }
1112  }
1113  STATUS(endl);
1114
1115  outputFile.put(job);
1116  outputFile.put(cpu);
1117  outputFile.put(rms);
1118  outputFile.put(rad);
1119  outputFile.put(*gRandom);
1120
1121  JMultipleFileScanner<JTYPELIST<JMetaTypes_t, MultiHead>::typelist> io(inputFile);
1122
1123  io >> outputFile;
1124
1125  outputFile.close();
1126 }
mc_usr_keys::energy_lost_in_can
const char *const energy_lost_in_can
Definition: io_ascii.hh:46
JSUPPORT::JMeta
Auxiliary class for ROOT I/O of application specific meta data.
Definition: JMeta.hh:70
JGEOMETRY2D::JVector2D
Data structure for vector in two dimensions.
Definition: JVector2D.hh:32
JSUPPORT::JFileRecorder
Object writing to file.
Definition: JFileRecorder.hh:42
JPARSER::JParser
Utility class to parse command line options.
Definition: JParser.hh:1711
JLANG::JException
General exception.
Definition: JException.hh:24
JLANG::make_predicate
JPredicate< JResult_t T::*, JComparison::eq > make_predicate(JResult_t T::*member, const JResult_t value)
Helper method to create predicate for data member.
Definition: JPredicate.hh:128
K
static const uint32_t K[64]
Definition: crypt.cc:77
JPHYSICS::EErad_t
static const JRadiationSource_t EErad_t
Definition: JRadiation.hh:510
JDETECTOR::JModule
Data structure for a composite optical module.
Definition: JModule.hh:67
E
then usage $script< input file >[option[primary[working directory]]] nWhere option can be E
Definition: JMuonPostfit.sh:40
JSIRENE::JHits_t::merge
void merge(const double Tmax_ns)
Merge hits on same PMT that are within given time window.
Definition: JSirene.hh:148
DZ
then let DZ
Definition: module-Z:fit.sh:71
JSIRENE::JTrk_t
Auxiliary class to set-up Trk.
Definition: JSirene.hh:188
JAANET::getTransformation
JTransformation3D getTransformation(const Trk &track)
Get transformation.
Definition: JAAnetToolkit.hh:283
distance
std::vector< T >::difference_type distance(typename std::vector< T >::const_iterator first, typename PhysicsEvent::const_iterator< T > second)
Specialisation of STL distance.
Definition: PhysicsEvent.hh:434
gmake_property
#define gmake_property(A)
macros to convert (template) parameter to JPropertiesElement object
Definition: JProperties.hh:1293
safetyFactor
double safetyFactor
safety factor for average CDF integral of optical module
Definition: JSirene.cc:70
JAANET::simul
Generator for simulation.
Definition: JHead.hh:526
JPHYSICS::getIndexOfRefraction
double getIndexOfRefraction()
Get average index of refraction of water corresponding to group velocity.
Definition: JPhysics/JConstants.hh:134
STATUS
#define STATUS(A)
Definition: JMessage.hh:63
JPHYSICS::SCATTERED_LIGHT_FROM_EMSHOWER
scattered light from EM shower
Definition: JPDFTypes.hh:38
JAANET::has_neutrino
bool has_neutrino(const Evt &evt)
Test whether given event has an incoming neutrino.
Definition: JAAnetToolkit.hh:477
JDETECTOR::JDetector
Detector data structure.
Definition: JDetector.hh:89
JAANET::is_muon
bool is_muon(const Trk &track)
Test whether given track is a (anti-)muon.
Definition: JAAnetToolkit.hh:339
JPHYSICS::JACoeffSource
Implementation for calculation of ionization constant.
Definition: JACoeffSource.hh:48
JSIRENE::getHitType
JHitType_t getHitType(const JPDFType_t pdf, const bool shower=false)
Get hit type corresponding to given PDF type.
Definition: JSireneToolkit.hh:151
JSIRENE::ns
std::vector< size_t > ns
Definition: JSireneToolkit.hh:138
JCALIBRATE::JParameters
Auxiliary class for PMT parameters including threshold.
Definition: JParameters.hh:21
JPHYSICS::getDeltaRaysFromTau
double getDeltaRaysFromTau(const double E)
Equivalent EM-shower energy due to delta-rays per unit tau track length.
Definition: JPDFToolkit.hh:95
JEEP::JProperties
Utility class to parse parameter values.
Definition: JProperties.hh:497
JPHYSICS::H
static const double H
Planck constant [eV s].
Definition: JPhysics/JConstants.hh:29
parameters
*fatal Wrong number of arguments esac JCookie sh typeset Z DETECTOR typeset Z SOURCE_RUN typeset Z TARGET_RUN set_variable PARAMETERS_FILE $WORKDIR parameters
Definition: diff-Tuna.sh:38
JPARSER::initialised
Empty structure for specification of parser element that is initialised (i.e. does not require input)...
Definition: JParser.hh:84
JPHYSICS::gRock
static const JGeane_t gRock(2.67e-1 *0.9 *DENSITY_ROCK, 3.40e-4 *1.2 *DENSITY_ROCK)
Function object for energy loss of muon in rock.
JPHYSICS::gWater
static const JGeaneWater gWater
Function object for energy loss of muon in sea water.
Definition: JGeane.hh:381
JPHYSICS::DENSITY_SEA_WATER
static const double DENSITY_SEA_WATER
Fixed environment values.
Definition: JPhysics/JConstants.hh:44
JSIRENE::pythia
static const JPythia pythia
Function object for relative light yield as a function of GEANT particle code.
Definition: JPythia.hh:96
JAANET::getTime
double getTime(const Hit &hit)
Get true time of hit.
Definition: JAAnetToolkit.hh:105
outputFile
string outputFile
Definition: JDAQTimesliceSelector.cc:37
JGEOMETRY2D::JVector2D::getY
double getY() const
Get y position.
Definition: JVector2D.hh:74
APPLICATION_JSIRENE
static const char *const APPLICATION_JSIRENE
detector simulation
Definition: applications.hh:19
JPHYSICS::DIRECT_LIGHT_FROM_MUON
direct light from muon
Definition: JPDFTypes.hh:26
JAANET::coord_origin
Coordinate origin.
Definition: JHead.hh:730
JPHYSICS::JRadiationFunction
Fast implementation of class JRadiation.
Definition: JRadiationFunction.hh:32
JPHYSICS::JRadiationSource
Implementation for calculation of inverse interaction length and shower energy.
Definition: JRadiationSource.hh:89
KM3NETDAQ::range_type
JRange< int > range_type
Definition: JDQSimulator.cc:160
JSIRENE::JHits_t
Auxiliary data structure for list of hits with hit merging capability.
Definition: JSirene.hh:137
type
then set_variable PMT_FILE set_variable DAQ_FILE set_variable OUTPUT_FILE set_variable DETECTOR else fatal Wrong number of arguments fi JPrintTree f $DAQ_FILE type
Definition: JRandomEventRunByRun.sh:46
JAANET::is_neutrino
bool is_neutrino(const Trk &track)
Test whether given track is a neutrino.
Definition: JAAnetToolkit.hh:321
JPHYSICS::C
static const double C
Physics constants.
Definition: JPhysics/JConstants.hh:25
JPHYSICS::SCATTERED_LIGHT_FROM_MUON
scattered light from muon
Definition: JPDFTypes.hh:27
JSUPPORT::JLimit
Auxiliary class for defining the range of iterations of objects.
Definition: JLimit.hh:41
JPHYSICS::getThetaMCS
double getThetaMCS(const double E, const double x, const double X0, const double M, const double Q)
Get multiple Coulomb scattering angle.
Definition: JPhysicsSupportkit.hh:40
JPHYSICS::JDISSource
Implementation for calculation of inverse interaction length and shower energy due to deep-inelastic ...
Definition: JRadiationSource.hh:160
Vec
The Vec class is a straightforward 3-d vector, which also works in pyroot.
Definition: Vec.hh:12
JGEOMETRY3D::JCylinder3D
Cylinder object.
Definition: JCylinder3D.hh:39
JAANET::detector
Detector file.
Definition: JHead.hh:226
JEEP::getGITVersion
std::string getGITVersion(const std::string &tag)
Get GIT version for given GIT tag.
Definition: Jeep/JGITTags.hh:34
JAANET::getKineticEnergy
double getKineticEnergy(const double E, const double m)
Get kinetic energy of particle with given mass.
Definition: JAAnetToolkit.hh:784
JPHYSICS::JRadiation
Auxiliary class for the calculation of the muon radiative cross sections.
Definition: JRadiation.hh:34
JAANET::JHead
Monte Carlo run header.
Definition: JHead.hh:1234
JLANG::getInstance
T & getInstance(const T &object)
Get static instance from temporary object.
Definition: JObject.hh:75
make_field
#define make_field(A,...)
macro to convert parameter to JParserTemplateElement object
Definition: JParser.hh:2158
log10
set_variable E_E log10(E_{fit}/E_{#mu})"
JPHYSICS::geanz
static const JGeanz geanz(1.85, 0.62, 0.54)
Function object for longitudinal EM-shower profile.
JGEOMETRY2D::JVector2D::getX
double getX() const
Get x position.
Definition: JVector2D.hh:63
JAANET::getAxis
JAxis3D getAxis(const Trk &track)
Get axis.
Definition: JAAnetToolkit.hh:259
JEEP::JTimer
Auxiliary class for CPU timing and usage.
Definition: JTimer.hh:32
JAANET::getPosition
JPosition3D getPosition(const Vec &pos)
Get position.
Definition: JAAnetToolkit.hh:187
JPHYSICS::SCATTERED_LIGHT_FROM_DELTARAYS
scattered light from delta-rays
Definition: JPDFTypes.hh:33
NOTICE
#define NOTICE(A)
Definition: JMessage.hh:64
ERROR
#define ERROR(A)
Definition: JMessage.hh:66
JPHYSICS::DIRECT_LIGHT_FROM_EMSHOWER
direct light from EM shower
Definition: JPDFTypes.hh:37
JMATH::PI
static const double PI
Mathematical constants.
Definition: JMath/JConstants.hh:20
JSIRENE::JTrack
Muon trajectory.
Definition: JSireneToolkit.hh:247
JGEOMETRY3D::JCylinder3D::addMargin
void addMargin(const double D)
Add (safety) margin.
Definition: JCylinder3D.hh:172
JPHYSICS::Brems_t
static const JRadiationSource_t Brems_t
Definition: JRadiation.hh:511
JTOOLS::JRange::getRange
const range_type & getRange() const
Get range.
Definition: JRange.hh:135
JDETECTOR::JDetectorSubset
Detector subset with binary search functionality.
Definition: JDetectorSubset.hh:119
JDETECTOR::JDetectorSubset_t
Detector subset without binary search functionality.
Definition: JDetectorSubset.hh:38
JSIRENE::JVertex
Vertex of energy loss of muon.
Definition: JSireneToolkit.hh:334
Head
The Head class reflects the header of Monte-Carlo event files, which consists of keys (also referred ...
Definition: Head.hh:65
FATAL
#define FATAL(A)
Definition: JMessage.hh:67
JAANET::getOrigin
Vec getOrigin(const JHead &header)
Get origin.
Definition: JHeadToolkit.hh:297
JSYSTEM::getDate
const char * getDate()
Get current local date conform ISO-8601 standard.
Definition: JDateAndTime.hh:36
Trk::id
int id
track identifier
Definition: Trk.hh:16
JPHYSICS::DIRECT_LIGHT_FROM_DELTARAYS
direct light from delta-rays
Definition: JPDFTypes.hh:32
range
z range($ZMAX-$ZMIN)< $MINIMAL_DZ." fi fi typeset -Z 4 STRING typeset -Z 2 FLOOR JPlot1D -f $
Definition: module-Z:fit.sh:118
R
then JCookie sh JDataQuality D $DETECTOR_ID R
Definition: JDataQuality.sh:41
N
then usage $script< input file >[option[primary[working directory]]] nWhere option can be N
Definition: JMuonPostfit.sh:40
create_update_issues.origin
string origin
Definition: create_update_issues.py:4
JDETECTOR::load
void load(const std::string &file_name, JDetector &detector)
Load detector from input file.
Definition: JDetectorToolkit.hh:483
JPHYSICS::JGeanz::getMaximum
double getMaximum(const double E) const
Get depth of shower maximum.
Definition: JGeanz.hh:162
JSUPPORT::JMultipleFileScanner
General purpose class for object reading from a list of file names.
Definition: JMultipleFileScanner.hh:202
in
then fatal The output file must have the wildcard in the e g root fi eval JPrintDetector a $DETECTOR O IDENTIFIER eval JPrintDetector a $DETECTOR O SUMMARY JAcoustics sh $DETECTOR_ID source JAcousticsToolkit sh CHECK_EXIT_CODE typeset A EMITTERS get_tripods $WORKDIR tripod txt EMITTERS get_transmitters $WORKDIR transmitter txt EMITTERS for EMITTER in
Definition: JCanberra.sh:48
JPHYSICS::is_scattered
bool is_scattered(const int pdf)
Test if given PDF type corresponds to scattered light.
Definition: JPDFTypes.hh:165
JDETECTOR::JModule::transform
void transform(const JRotation3D &R, const JVector3D &pos)
Transformation of geometry (see method JGEOMETRY3D::JPosition3D::transform(const JRotation3D&amp;, const JVector3D&amp;)).
Definition: JModule.hh:345
JPHYSICS::is_deltarays
bool is_deltarays(const int pdf)
Test if given PDF type corresponds to Cherenkov light from delta-rays.
Definition: JPDFTypes.hh:151
JSIRENE::JHit_t
Auxiliary class to set-up Hit.
Definition: JSirene.hh:57
JGEOMETRY3D::JVector3D::getX
double getX() const
Get x position.
Definition: JVector3D.hh:94
JPHYSICS::getDeltaRaysFromMuon
double getDeltaRaysFromMuon(const double E)
Equivalent EM-shower energy due to delta-rays per unit muon track length.
Definition: JPDFToolkit.hh:67
JAANET::copy
void copy(const Head &from, JHead &to)
Copy header from from to to.
Definition: JHead.cc:162
JSYSTEM::ls
Auxiliary data structure to list files in directory.
Definition: JFilesystem.hh:18
JPHYSICS::getTanThetaC
double getTanThetaC()
Get average tangent of Cherenkov angle of water corresponding to group velocity.
Definition: JPhysics/JConstants.hh:156
JSIRENE::getNumberOfPhotoElectrons
struct JSIRENE::@61 getNumberOfPhotoElectrons
Auxiliary data structure for determination of number of photo-electrons.
JAANET::getNPE
double getNPE(const Hit &hit)
Get true charge of hit.
Definition: JAAnetToolkit.hh:117
Z
do set_variable MODULE getModule a $WORKDIR detector_a datx L $STRING JEditDetector a $WORKDIR detector_a datx M $MODULE setz o $WORKDIR detector_a datx JEditDetector a $WORKDIR detector_b datx M $MODULE setz o $WORKDIR detector_b datx done echo Output stored at $WORKDIR detector_a datx and $WORKDIR tripod_a txt JDrawDetector2D a $WORKDIR detector_a datx a $WORKDIR detector_b datx L BL o detector $FORMAT $BATCH JDrawDetector2D T $WORKDIR tripod_a txt T $WORKDIR tripod_b txt L BL o tripod $FORMAT $BATCH JCompareDetector a $WORKDIR detector_a datx b $WORKDIR detector_b datx o $WORKDIR abc root &dev null for KEY in X Y Z
Definition: JAlignDetector.sh:81
JGEOMETRY3D::JPosition3D
Data structure for position in three dimensions.
Definition: JPosition3D.hh:36
JSUPPORT::JLimit::getLimit
const JLimit & getLimit() const
Get limit.
Definition: JLimit.hh:84
JPHYSICS::JGeanz::getLength
double getLength(const double E, const double P, const double eps=1.0e-3) const
Get shower length for a given integrated probability.
Definition: JGeanz.hh:122
JAANET::get_neutrino
const Trk & get_neutrino(const Evt &evt)
Get incoming neutrino.
Definition: JAAnetToolkit.hh:497
detector
do set_variable DETECTOR_TXT $WORKDIR detector
Definition: detector-XY:fit1d.sh:38
JAANET::is_tau
bool is_tau(const Trk &track)
Test whether given track is a (anti-)tau.
Definition: JAAnetToolkit.hh:347
JPHYSICS::GNrad_t
static const JRadiationSource_t GNrad_t
Definition: JRadiation.hh:512
JGEOMETRY3D::JTransformation3D::transform
JPosition3D transform(const JPosition3D &pos) const
Transform position.
Definition: JTransformation3D.hh:49
D
do echo Generating $dir eval D
Definition: JDrawLED.sh:53
numberOfBins
int numberOfBins
number of bins for average CDF integral of optical module
Definition: JSirene.cc:69
JGEOMETRY3D::JVector3D::getZ
double getZ() const
Get z position.
Definition: JVector3D.hh:115
Evt::mc_trks
std::vector< Trk > mc_trks
MC: list of MC truth tracks.
Definition: Evt.hh:49
GAUSS_LEGENDRE::epsilon
const double epsilon
Definition: JQuadrature.cc:21
debug
int debug
debug level
Definition: archive-put-wiki-detectors.sh:92
Evt
The Evt class respresent a Monte Carlo (MC) event as well as an offline event.
Definition: Evt.hh:20
JTOOLS::accumulate
void accumulate(T &value, JBool< false > option)
Accumulation of value.
Definition: JToolsToolkit.hh:321
DEBUG
#define DEBUG(A)
Message macros.
Definition: JMessage.hh:62

Variable Documentation

int debug

debug level

Definition at line 68 of file JSirene.cc.

int numberOfBins = 200

number of bins for average CDF integral of optical module

Definition at line 69 of file JSirene.cc.

double safetyFactor = 1.7

safety factor for average CDF integral of optical module

Definition at line 70 of file JSirene.cc.

Generated by   doxygen 1.8.5
